Turbosound NuQ102-AN 600 Watt 2 Way 10" Full Range Powered Loudspeaker with KLARK TEKNIK DSP Technology and ULTRANET Networking. The 2-way full ran...

1,280,000.00

10 visitors are looking this product!

Turbosound NuQ102-AN 600 Watt 2 Way 10" Full Range Powered Loudspeaker with KLARK TEKNIK DSP Technology and ULTRANET Networking.

The 2-way full range NuQ102-AN is a 600 Watt 10" powered loudspeaker system that is ideally suited for a wide range of portable and fixed installation speech and music sound reinforcement applications. Designed to work individually without a controller, the NuQ102-AN provides optimal performance for FOH, sidefill and delay line loudspeakers, and is an exceptional choice for wedge monitoring applications. It also offers the flexibility to accommodate venue-specific requirements for install applications.



The NuQ102-AN loudspeaker features a 10" low frequency driver with a low ass voice coil for improved transient response and an aluminium dome 1" neodymium high frequency compression driver, which is mounted on a rotatable 100° horizontal by 60° vertical dispersion converging elliptical waveguide.



Output power for the NuQ102-AN is provided by means of an efficient and lightweight Klark Teknik 600-Watt Class-D power amplifier. A sophisticated, but easy to use Klark Teknik Digital Signal Processor (DSP) provides dynamic EQ for impressive full range response at low volume levels and transparent limiting for clarity at high output levels – and for long-term reliability.



On the rear panel of the amplifier module, the user interface’s LCD display and single rotary encoder provide intuitive access to: position compensation, user EQ control, subwoofer integration and signal routing features. In addition to the balanced XLR input, an XLR output is provided for daisy-chaining more active loudspeakers or for use with active subwoofers. An onboard USB port provides access for remote control of the NuQ102-AN via PC computer, as well as DSP firmware updates.



ULTRANET connectivity is provided by two locking etherCON* connectors. Up to 16 independent channels of 24-bit digital audio and control data are transmitted via a single CAT5 cable between compatible digital devices – including mixers, I/O stage boxes, powered loudspeakers and personal monitoring systems. Simplified cable routing and ease of setup translate directly into significant time saved during installation.



Finished in a highly durable semi matt black paint, the trapezoidal cabinet is constructed from 12 mm (½") birch plywood – and includes a rugged powder coated perforated steel mesh grille. Multiple threaded rigging points are provided for suspension in any orientation. The NuQ102-FY flying yoke kit, NuQ102-SB swivel bracket, and NuQ102-EB swivel extender provide added flexibility in permanent install applications (available separately). The NuQ102-AN also features a 35 mm socket for standard pole mounting – plus integrated handles for convenient transport. Mains power input is provided via a Neutrik powerCON* connector.

Specification
System
Frequency Response

55 Hz – 18 kHz ±3 dB
50 Hz – 20 kHz -10 dB

Nominal Dispersion

100° H x 60° V @ -6 dB points, rotatable

Maximum SPL

122 dB peak

Crossover Type

Active

Transducers

1 x 10" (261.5 mm) LF driver
1 x 1" (25.4 mm) HF compression driver

Limiter

Independent HF, LF, peak and rms

Amplifier
Maximum Output Power*

600 W

Type

Class-D

Protection

Short circuit, thermal

Connectors
Input/link

1 x Combo Jack/XLR 1 x XLR

Ultranet input/link

2 x RJ45

Mains Supply

Neutrik powerCON 20A†

Controls
DSP

Rotary push-encoder and level control
Buttons for Process, Setup, Exit, Enter

User DSP Functions
Factory EQ Presets

Positioning, Sound mode, FBQ

Display

LCD 128 x 32, blue, backlit

Delay

0 - 300 ms

Equalisation

High and low shelving EQ
2 x parametric EQ

Limiter

Zero attack input limiter

Presets

20 total presets, 19 user-definable

Crossover

High Pass L-R 24 dB/oct

Protection

Lock-out function for all settings

Ultranet Digital Network
Digital processing
System
Cabling
Power Supply
Power consumption

80 W @ 1/8 max power

Voltage (fuses)
Enclosure
Dimensions HWD

525 x 318 x 281 mm (20.7 x 12.5 x 11.1")

Net weight

13.7kg (30.2 lbs)

Construction

12 mm (½") birch plywood

Finish

Semi matt white paint

Grille

Powder coated perforated steel

Flying hardware

M10 x 8 points; M8 x 1 point

Accessories

NuQ102-SB swivel bracket for NuQ102
NuQ102-EB extension bracket for NuQ102
NuQ102-FY flying yoke for NuQ102
